Utilities EPC
-
High-EfficiencyN/A
-
Watt Range250wp - 300wp
-
CustomisedNot Customised
-
Datasheet
KEY FEATURES
-
TechnologyPoly / Mono Crystalline Cells
(High efficiency, selected grade) -
Glass3.2mm Tempered Glass with Anti-Reflective (AR) Coating
-
Power TolerancePositive Power Sorting
(to reduce mismatch losses) -
Quality TestingPre & Post EL Inspection with High-Resolution Camera
-
DurabilityIP68 Junction Box with 3 Bypass Diodes
-
CompatibilityWorks with 12V / 24V / 36V / 48V Systems
-
FrameHigh Tensile Anodised Aluminium (Silver)
FEATURES & WARRANTY
The Universal Plus U-Series from KOSOL is a versatile range of solar PV modules designed for a wide spectrum of applications, including residential, commercial, industrial, agriculture, off-grid systems, and portable solar solutions.
BENEFITS
-
Wide CompatibilitySupports 12V / 24V / 36V / 48V systems for flexible use.
-
Low-Light PerformanceDelivers stable power even in cloudy or low-sunlight conditions.
-
Higher EfficiencyPositive power sorting reduces mismatch losses.
-
Weather ProtectionIP68 junction box safeguards against water and dust.
-
Low MaintenanceDesigned for minimal upkeep and consistent output.
| Maximum Power (Pmax) | 20Wp – 350Wp |
| Current (Imp) | Varies by model |
| Open Circuit Voltage (Voc) | Varies by model |
| Short Circuit Current (Isc) | Varies by model |
| Module Efficiency | Up to 17–19% |
| Power Tolerance | 0 to +3% |
| Glass | 3.2mm AR Coated Tempered Glass |
| Frame | Anodized Aluminium (Silver) |
| Junction Box | IP68, 3 Bypass Diodes |
| Connector | MC4 / Compatible |
| Cable | 4 sq.mm, 900–1000 mm |
| Model | Dimensions (mm) |
|---|---|
| 75W | 755 × 635 × 30 |
| 100W | 825 × 665 × 30 |
| 150W | 1120 × 665 × 30 |
| 160W | 1485 × 903 × 30 |
| 200W | 1485 × 903 × 35 |
| 250W | 1485 × 903 × 35 |
PORTABLE SOLAR CHARGER
RV & CARAVAN POWER SYSTEMS
REMOTE AREA POWER SUPPLY
CAMPING & HIKING GEAR
SOLAR-POWERED BOATS
VEHICLE SOLAR ROOF SYSTEMS
- Integrated solar roofs for buses, trucks, vans, and transport fleets.
